Cornelius VENTURE - Figure 6. Inlet Supply Line Connections

19
318832000
* This CAPPED CROSS FITTING is used when converting No. 3 dispensing valve from
a still ( noncarbonated ) to a carbonated drink. Refer to TABLE OF CONTENTS for con-
version instructions.
1
2
3
4
5
6
DISPENSING VALVE
BLOCK
DISPENSING VALVE
RELEASE LATCH
LABELED UNIT
INLET LINES
*CAPPED CROSS FITTING
(CARBONATED WATER)
FIGURE 6. INLET SUPPLY LINE CONNECTIONS (UNIT WITH BUILT-IN COLD CARBONATOR)
