2. Remove Unit hood by loosening screw on top of hood, then lift hood straight up off Unit.
3. Remove plug from drop-in refrigeration assembly platform water fill hole (see Figure 8).
4. Using a flashlight, inspect ice water bath and ice bank for cleanliness. Ice water bath should be clear and
ice bank free of foreign particles.
5. If cleaning of water tank is necessary, refer to CLEANING WATER TANK in this section.
6. Fill water tank with clean water to top of stainless steel coils located in coil basket. USE LOW-MINERAL-
CONTENT WATER WHERE A LOCAL WATER PROBLEM EXISTS.
7. Install plug in water fill hole.
8. Install Unit hood and secure with screw.
9. Plug Unit power cord into electrical outlet.
CLEANING WATER TANK
1. Unplug Unit power cord from electrical outlet.
2. Remove two screws (if applicable) securing Unit front access panel, then remove panel.
3. Route water tank drain hose to a drain. Remove plug from end of drain hose and allow water tank to drain.
4. Remove Unit hood by loosening screw on top of hood, then lift hood straight up off Unit.
5. Unplug drop-in refrigeration assembly power cord and electric dispensing valves power cord.
Unit Equipped with Built-in Cold Carbonator.
A. Disconnect built-in cold carbonator power cord (see Figures 8 and 9).
B. Loosen screw on water pump-to-motor coupling (see Figure 10), then slide water pump off motor
shaft. Lay water pump, with attached lines, off to one side.
6. Lift drop-in refrigeration assembly up and out of Unit.
CAUTION: Never use an ice pick or other instrument to remove ice from drop-in
refrigeration assembly evaporator coils. Such practice can result in punctured refrigeration
circuit.
7. Allow ice bank to melt. Hot water may be used to speed melting.
8. Use fiber brush and carefully clean mineral deposit build-up from agitator motor shaft and ice bank sensing
bulb.
9. Wash inside of water tank and drop-in refrigeration assembly evaporator coils, then rinse with clean water.
10. Install plug in end of water tank drain hose.
11. Install drop-in refrigeration assembly in Unit by reversing removal procedure.
