12
318832000
UNITS WITH 1/4 H.P. REFRIGERATION AND BUILT-IN COLD CARBONATOR
Item
No. Part No. Name 4FL 5FL 6FL
1 317659039 Drip Tray 1 1 1
2 317660000 Cup Rest 1 1 1
3 317792000 Line Outlet Plug 1 1 1
4 77070402 Fitting, Stainless Steel, 5/8-18 (2) 1 1 1
5 176017000 Swivel Nut, 7/16-20 1 1 1
6 311304000 Tapered Gasket, Black 3 3 3
7 77010400 Nipple, 7/16 Nut (for .265 Tube) 1 1 1
8 300200000 Tubing Clamp 1 1 1
SELECTING LOCATION
CAUTION: This Unit is intended for indoor installation only. Do not install this Unit in an
outdoor environment which would expose it to the outside elements.
This Unit may be island-mounted or installed on a front or rear counter. Locate the Unit so the following require-
ments are satisfied:
WARNING: To avoid possible fatal electrical shock or serious injury to the operator, it is
highly recommended that a GFCI (ground fault circuit interrupt) be installed in the
electrical circuit for the domestic Units. It is required that an ELCB (earth leakage circuit
breaker) be installed in the electrical circuit for the export Units
1. The Unit must be installed near a properly grounded electrical outlet with proper electrical require-
ments.The electrical circuit must be properly fused (slow-blow type fuse) or the circuit must be connected
through an equivalent HACR circuit breaker.The electrical outlet must be accessible for ease of connecting
and disconnecting the Unit power cord. No other electrical equipment should be connected to this circuit.
REFER TO UNIT NAMEPLATE FOR THE REQUIRED POWER CIRCUIT OPERATING VOLTAGE, HZ,
AND THE MINIMUM CIRCUIT AMPACITY OF THE UNIT. ALL ELECTRICAL WIRING MUST CONFORM
TO NATIONAL AND LOCAL ELECTRICAL CODES.
CAUTION: Do not place or store anything on top of the Unit.
2. A minimum of 15-inches clearance must be maintained above the Unit to the nearest obstruction (shelf,
cupboard, ceiling, etc.) and 6-inches clearance between back-side of the Unit and the wall. The front grille
of the Unit must be unobstructed to allow air to enter the hood.
3. Close to a permanent drain to route drip tray drain hose and water tank drain hose.
4. The top of the unit is to remain free of all objects. Do not place anything on top of unit.
