WARNING: CO
2
displaces oxygen. Strict attention must be observed in the prevention of
CO
2
(carbon dioxide) gas leaks in the entire CO
2
and soft drink system. If a CO
2
gas leak is
suspected, particularly in a small area, immediately ventilate the contaminated area before
attempting to repair the leak. Personnel exposed to high concentration of CO
2
gas will experience
tremors which are followed rapidly by loss of consciousness and suffocation.
STANDARD UNIT REQUIRING CONNECTION TO A REMOTE CARBONATOR
(see Figure 2)
1. Open (counterclockwise) CO
2
cylinder shutoff valve slightly to allow lines to slowly fill with gas, then open
valve fully to back-seat valve. (back-seating valve prevents leakage around valve shaft). Check for CO
2
leaks.
2. Adjust primary CO
2
regulator (regulator controls carbonator CO
2
pressure) as instructed in manual pro-
vided with the carbonator. Check for CO
2
leaks.
3. Open plain water inlet supply line shutoff valve. Check for water leaks and tighten any loose connections.
4. Plug remote carbonator power cord into electrical outlet. Carbonator will start and continue to operate until
carbonated water tank is full.
5. Adjust syrup tanks system or bag-in-box syrup system syrup pumps secondary CO
2
regulator as instructed
in SERVICE AND MAINTENANCE section of this manual.
6. Sanitize all syrup systems as instructed in SERVICE AND MAINTENANCE section of this manual.
7. Install syrup tanks or bag-in-boxes containing syrup into syrup systems.
UNIT WITH BUILT-IN COLD CARBONATOR
(see Figure 3)
1. Open (counterclockwise) CO
2
cylinder shutoff valve slightly to allow lines to slowly fill with gas, then open
valve fully to back-seat valve. (back-seating valve prevents leakage around valve shaft). Check for CO
2
leaks.
2. Adjust primary CO
2
regulator (regulator controls Unit built-in cold carbonator CO
2
pressure) as instructed in
SERVICE AND MAINTENANCE section of this manual. Check for CO
2
leaks.
3. Open plain water inlet supply line shutoff valve. Check for water leaks and tighten any loose connections.
4. Flip carbonator water pump motor power switch (located on refrigeration assembly control box) to “ON”
position. Carbonator water pump will start and continue to operate until carbonator tank has been filled,
then pump motor will stop. Check for CO
2
, plain water, and carbonated water leaks and tighten any loose
connections.
5. Adjust syrup tanks system or bag-in-box syrup system syrup pumps secondary CO
2
regulator as instructed
in SERVICE AND MAINTENANCE section of this manual.
6. Sanitize all syrup systems as instructed in SERVICE AND MAINTENANCE section of this manual.
7. Install syrup tanks or bag-in-boxes containing syrup into syrup systems.
NONCARBONATED UNIT
(see Figure 4)
1. Open plain water inlet supply line shutoff valve. Check for water leaks and tighten any loose connections.
