Cornelius VENTURE - Connecting Carbonated Water Source Line to Unit; Connecting Co2 Source Line to Unit; Connecting Syrup Source Lines to Unit; Preparation for Operation

15
318832000
CAUTION: Check the minimum flow rate and maximum pressure of plain water inlet supply
line. MINIMUM FLOW RATE MUST BE AT LEAST 100-GALLONS PER HOUR. If flow rate is
less than 100-gallons per hour, starving of carbonator water pump will occur. Starving will
allow water pump to overheat and will damage the pump. Overheating could occur if plain water
inlet supply line flow rate drops below 100-gallons per hour. CARBONATOR CO
2
OPERATING
PRESSURE MUST EXCEED WATER PRESSURE BY 10-PSI. (Example: CO
2
operating pressure is
80-psi, maximum water pressure can be no more than 70-psi, etc.) Water over pressure (higher
than CO
2
operating pressure) can cause carbonator flooding, malfunction, and leakage through
carbonator relief valve. If water is exceeding maximum pressure specifications, a Water Pressure
Regulator Kit (P/N 317589000) or equivalent must be installed in plain water inlet supply line.
Standard Unit Requiring Connection to a Remote Carbonator. (see Figure 2)
1. Install ADAPTOR FITTING, provided with the Unit, in end of Unit labeled plain water inlet line.
2. Connect plain water source supply line to Unit labeled plain water inlet line.
Unit With Built-In Cold Carbonator. (see Figure 3)
Connect plain water source line to Unit labeled plain water inlet lines.
NonCarbonated Unit. (see Figure 4)
(see Figure 4)
Connect plain water source lines to Unit labeled plain water inlet lines.
CONNECTING CARBONATED WATER SOURCE LINE TO UNIT
Standard Unit Requiring Connection to a Remote Carbonator. (see Figure 2)
Connect carbonated water source line from remote carbonator to labeled Unit carbonated water inlet line.
CONNECTING CO
2
SOURCE LINE TO UNIT
Unit With Built-In Cold Carbonator. (see Figure 3)
Connect CO
2
source line to Unit labeled CO
2
inlet line.
CONNECTING SYRUP SOURCE LINES TO UNIT
(see applicable Figure 2, 3, or 4)
Connect syrup source lines to Unit labeled syrup inlet lines.
PREPARATION FOR OPERATION
CAUTION: Before opening CO
2
cylinder shutoff valve, turn secondary CO
2
regulators
adjusting screws to the left (counterclockwise) until all tension is relieved from adjusting
screws springs.
