INSTALLATION
This section covers unpacking and inspection, selecting location, installing Unit, preparing for operation, and
operation.
UNPACKING AND INSPECTION
NOTE: The Unit was thoroughly inspected before leaving the factory and the carrier has accepted and
signed for it. Any damage or irregularities should be noted at the time of delivery (or not later than 15
days from date of delivery) and immediately reported to the delivering carrier. Request a written inspec-
tion report from Claims Inspector to substantiate any necessary claim. File claim with the delivering
carrier, not with IMI Cornelius Inc.
1. After Unit has been unpacked, remove shipping tape and other packing material.
2. Lift hood straight up and off Unit.
3. Remove four shipping nuts that secure drop-in refrigeration assembly in Unit.
4. Remove two screws (if applicable) securing front access panel to Unit, then remove panel.
5. Unpack LOOSE-SHIPPED PARTS. Make sure all items are present and in good condition.
CARBONATED UNITS WITH 1/3 H.P. REFRIGERATION
(REQUIRES CONNECTION TO A REMOTE CARBONATOR)
Table 2. Loose-Shipped Parts
Item
No. Part No. Name 4-FL 5-FL 6-FL
1 317659039 Drip Tray 1 1 1
2 317660000 Cup Rest 1 1 1
3 317792000 Line Outlet Plug 1 1 1
4 176193000 Fitting, 7/16-20 (2) 5 6 7
NONCARBONATED UNITS WITH 1/3 H.P. REFRIGERATION
Item
No. Part No. Name 5-FL 6-FL
1 317659039 Drip Tray 1 1
2 317660000 Cup Rest 1 1
3 317792000 Line Outlet Plug 1 1
4 176193000 Fitting, 7/16-20 (2) 6 7
5 318523088 Test Baffle Ass’y, Dispensing Valve (see Note below) 1 1
NOTE: Temporarily used to adjust dispensing valves for Water-To-Syrup “Ratio” of dispensed product.
