Crestron Mobile Pro App / XPanel for Mac Prodigy
®
System
To set the temperature:
• Single Setpoint:
Touch k or j to raise or lower the temperature setting.
NOTE: When using a single setpoint, there is a 20-minute change
limiter to prevent system toggling.
• Dual Setpoints:
1. Verify that the controlled zone is set to the Auto mode.
2. To lower the heating or cooling setpoint, touch the j button
under the setting to be changed. To raise the heating or
cooling setpoint, touch the k button under the setting to be
changed.
Set the System Mode
A Prodigy-controlled HVAC zone has up to five operating modes:
NOTE: Not all modes are available for all HVAC zones.
• OFF: In Off mode, all HVAC systems are disabled.
• HEAT: In Heat mode, the thermostat uses the heating system to
maintain the setpoint temperature. On the P-TSTATRF, a “flame”
icon will be displayed.
• AUXILIARY (AUX) HEAT MODE: In Auxiliary Heat mode, the
thermostat uses only the auxiliary heat output on heat pump or dual-
fuel systems (if equipped) to maintain the setpoint temperature. This
setting can be useful when the heat pump is being serviced or when
there is an unexpected problem with it. On the P-TSTATRF, the
display will flash the “flame” icon when the system is in Auxiliary
Heat mode.
• COOL: In Cool mode, the thermostat uses the cooling system to
maintain the setpoint temperature. On the P-TSTATRF, the
“snowflake” icon will be displayed.
• AUTO: In Auto mode, the thermostat allows the system to switch
between Heat and Cool automatically as needed to maintain the
setpoint temperature. On the P-TSTATRF, the display will show the
“flame” and “snowflake” icons.
System User Guide – DOC. 7007B Prodigy System: PMC2 • 87
