4 — PROGRAMMABLE PARAMETERS
pg. 39
Return to TOC Curtis AC F4-A Motor Controller – August 2020
AC MOTOR SETUP ............................. p. 109
~ Max Speed Controller Limit
Typical Max Speed
~ Motor Technology
— INDUCTION MOTOR............. p. 110
— Swap Two Phases
Motor Type
FIELD WEAKENING....... p. 110
~ Base Speed Captured
— FW Base Speed
~ Test Field Current
— Field Weakening Drive
Weakening Rate Drive
— Min Field Current
— Limited Operating Strategy
(LOS)........................ p. 112
— LOS Upon Encoder Fault
— LOS Max Speed
— LOS Max Current
— LOS Max Mod Depth
— LOS Accel Rate
— LOS Decel Rate
— CHARACTERIZATION
TESTS...................... p. 112
— Test Enable
— Test Throttle
— Motor Poles
— Max Test Speed
— Max Test Current
— SlipGain
— Current Reg Tuning Test Enable
— Position Sensor Type
(encoder)*........................ p. 113
— QUADRATURE ENCODER...... p. 114
— 5V Output Enable
— 12V Output Enable
— Encoder Steps
— Swap Encoder Direction
ENCODER FAULT
SETUP...................... p. 114
— Fault Detection Enable
— Encoder Pulse Fault
Detact Time
— Fault Stall Time
— TEMPERATURE SENSOR...... p. 115
— Sensor Enable
~ Temperature
~ Motor Temp Cutback
— Temperature Hot
— Temperature Max
— Motor Temp LOS Max Speed
Sensor Type
— Sensor Offset
IO ASSIGNMENTS ........................... p. 100
— CONTROLS............................. p. 100
— Interlock Input Source
— Forward Input Source
— Reverse Input Source
— Throttle Source
— Brake Source
— Dual Steer Source
~ EMR State
— EMR Switch Source NO
— EMR Switch Source NC
— Hydraulics Inhibit Type
— Lift Input Type
— Lift Input Source
— Lift Limit Switch Type
— Lift Limit Switch Source
Lower Input Type
— Lower Input Source
— SWITCH STATUS..................... p. 102
~ Switch 1 – 27
— COIL DRIVERS........................ p. 104
— Main Contactor Driver
— EM Brake Driver
— Pump Contactor Driver
— Load Hold Driver
EXTERNAL SUPPLIES........................ p. 105
— 5V Output Enable
— 12V Output Enable
~ 5V Measured
~ 5V Supplied Current
~ 12V Measured
~ 12V Supplied Current
~ Total Supplied Current
— 5V Supply Min
— 5V Supply Max
— 12V Supply Min
— 12V Supply Max
CURRENT LIMITS ............................ p. 106
— Drive Current Limit
— Regen Current Limitt
— Brake Current Limit
— EMR Current Limit
— Interlock Brake Current Limit
— Pump Drive Current Limit
POWER LIMITS.................... p. 106
— Nominal Speed
— Delta Speed
DRIVE LIMITING MAP... p. 107
— Nominal
— Plus Delta
— Plus 2xDelta
— Plus 4x Delta
— Plus 8x Delta
REGEN LIMITING MAP.... p. 108
— Nominal
— Plus Delta
— Plus 2xDelta
— Plus 4x Delta
— Plus 8x Delta
OUTPUTS ........................................ p. 104
— Driver Output Frequency
— Coil Supply Start Up Checks
— DRIVER X (1 – 7)................... p. 104
— Driver X Checks Enable
— Driver X Overcurrent Disable Supply
Quick Link:
Table 13 p.22
* Encoder option shown. See Table 13 for Sin/Cos option.
