CVC TECHNOLOGIES, INC. FRONT/BACK LABELER CVC 400 OPERATION MANUAL
5. INSTALLATION PROCEDURES
5.1 Power Connection
Connection of the electricity supply to the machine is necessary for the operation of its electrical
components. Only use 3-hole socket and properly grounded.
a. Connect the main power cord of the machine to the safety NFB breakers on the power source,
ensuring that the voltage and amperage meet machine’s requirements.
b. And disconnect the machine power immediately if water is on or near the power source of the
control panel.
Fig 5.1-1
5.2 Compressed Air Connection (Optional)
Connect the air pressure inlet adapter into the compressed air inlet socket of the machine for hot
stamp printer.
Air socket
Air adapter
5 - 1
Fig 5.2-1
