CVC 400 - Hot Stamp Printer Specifications (Optional)

CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
2.3 Hot Stamp Printer Specifications (Option)
Model: C60
Print Type Nickel alloy for standard sizes, brass for 1.3 mm type
Print Sizes Standard size: 1.5mm, 2.0mm, 2.5mm
Special size: 1.3mm
Air Consumption
50
ℓ/min (based on 300 strokes per minute)
Air Pressure 4 ~5 kgf/cm
2
(60 ~80 psi)
Printing Lines 1~6 lines
Print Speed (max.) 300 prints/min.
Hot Foil Ribbon 1. Two types are available
A. Width: 25mm (1")
B. Width: 32mm (1
1
/
4
")
2. Applicable printing temperature: 50˚C ~ 200 ˚C
Foil Printing Temperature 130 ˚C ~200˚C
Print Area Max. Length: 70mm (2
3
/
4
"),
Max Width: 65mm (2
1
/
2
")
2.3.1 Print Area
Max.: 65mm
Max.: 70mm (2
3
/
4
")
(2
2
1
/ ")
Fig 2.3-1
2 - 6
