CVC 400 - 14 Electrical Diagrams; Electric Pin Descriptions

CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
14 - 2
14.1 ELECTRIC Pin Description
14.1.1 Side-Plate (Power Box)
※ Labeling Head B (Left, X1), Labeling Head A (Right, X2)
J29
Stepper Motor Coil
Labeling Head B (Left, X1) Labeling Head A (Right, X2)
Pin No. Color Definition Pin No. Color Definition Pin No. Color Definition
1 6 11
2 RED A 7 RED A 12
3 YEL A’ 8 YEL A’ 13
4 ORG B 9 ORG B 14
5 BLU B’ 10 BLU B’ 15
J30
DC Motor Coil & AC 110 V Power
Pin No. Color Definition Pin No. Color Definition Pin No. Color Definition
1 6 BLK Conveyor 11
2 WHT AC+(110V Printer) 7 WHT Wrap, P&P Station 12
3 BLK AC- (110V Printer) 8 BLK Wrap, P&P Station 13
4 9 WHT Separator 14
5 WHT Conveyor 10 BLK Separator 15
J33
DC Power & Signal Output
Pin No. Color Definition Pin No. Color Definition Pin No. Color Definition
1 6 YEL DC24 V 11
2 7 GRN DC 24 VG 12
Head B (left, X1)
Printing signal output
DC 24V
3 8 13
4 9 14
5 10 15 RED
Head A (right, X2)
Printing signal output
DC 24V
