CVC 400 - Label Wipe-On Roller Mounting

CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
9.3 Label Wipe-on Roller Mounting (Option)
For proper front/back labeling, the wipe-on roller on each side should be mounted as shown in Fig
9.3-2. The distance from the peel blade should be carried out proper adjustment before labeling.
Fig 9.3-1 Fig 9.3-2
9 - 5
