CVC 400 - 15 Parts List

CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
15 - 1
15. PARTS LIST
15.1 Recommended Spare Parts for Labeler
No. Part Number Description
Quantity
1
WL 4G-3N1382P01
WL9-2N
Product sensor (SICK):
Standard, for general container
Optional, Special type for transparent container with dry
powder 1
2
LABEL-7P Label sensor
1
3
4 Amp/6 Amp Fuses 10
4
09A11000+09A12000
Rewind spool + spool inserter 3
5
90D05000 Separator wheel
2
6
92Q52A00 Label roller (A)* (Dia.160mm, H: 80mm)
2
7
92Q52C00 Label roller (C )* (Dia.160mm, H:151mm)
2
8
92Q52E00 Label roller (E)* (Dia.160mm, H: 220mm)
2
9
09H23D10 Spring for brake strap (240mm) 2
10
09H23D00 Spring for brake strap (41mm) 2
11
660DL075 Toothed belt for top hold-down bar
2
12
M1800 Toothed belt for top hold-down bar
4
13
168XL075 Toothed belt for top hold-down bar
2
14
290XL075 Toothed belt for alignment device
2
15
76XL037 Toothed belt for alignment device
2
16
96XL037 Toothed belt for alignment device
2
17
255L075U Toothed belt for conveyor 2
18
390L075U Toothed belt for conveyor 2
19
450L075U Toothed belt for conveyor 1
20
200XL050 Toothed belt for labeling head 1
21
146XL075 (S2000006) Toothed belt for labeling roller, P&P (optional) 1
22
135LL075 (S2000235) Toothed belt for labeling roller, P&P (optional) 1
23
160XL062U
(S2000008) Toothed belt for P&P (optional) 1
24
92Q14C00 Push & Press Sponge, (C Type), (Optional) 1
25
W1230435 E3XNA11+E32CC200 1
26
C7 (DRV5) Stepper motor drive for labeling head 1
27
C10 (DCMD) Motor drive for conveyor 1
* (A), (C), (E) above indicate model CVC 400A, CVC 400C, CVC 400E respectively.
