CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
11.11 Label Extension (EXTNSN) Adjustments
a. F2 EXTNSN refers to the length of label portion that extends beyond the tip of the peel blade. See the
following illustration.
Fig
11.11-1
b. Normally F2 EXTNSN ranges between 1 and 5mm. In some special cases the distance may be
longer than 5mm.
c. Normally the SelfSet
TM
will calculate the correct distance and no change is required.
d. The constant extension length is necessary. If the extension length is inconstant every time, it may
cause inaccurate labeling and unqualified products.
e. To change the label extension, first locate the label extension display:
11 - 7
→ or key → key → key → Memory (job) # → key
f. Use and to select between labeling head A or B.
