Digital I/O
Pin No. Color Definition Pin No. Color Definition Pin No. Color Definition
1 BRN
DC 12 V
Encoder,
Backlog sensor
6 WHT
Conveyor encoder
PH B
11 BLK Product sensor
2 BRN
DC 12 V
Clear label sensor,
Product sensor,
P&P sensor,
7 WHT
Wrapping encoder
PH A
12 BLK P&P sensor
3 BLU
DC 12 VG
Clear label sensor,
Product sensor,
P&P sensor,
8 GRN
Wrapping encoder
PH B
13
4 BLU
DC12 VG
Encoder,
Backlog sensor
9 PPL
Head B (Left, X1)
Clear label sensor
14
5 GRN
Conveyor encoder
PH A
10 PPL
Head A (Right, X2)
Clear label sensor
15
J32
Analog I/O & Digital Input
Pin No. Color Definition Pin No. Color Definition Pin No. Color Definition
1 6 RED
Analog voltage output
DLAV2 (Head A, Right)
Label sensor
11 PPL
Head B (Left, X1)
Ribbon sensor
2 WHT
DC 12VG,
Label sensor
7 BLK
Analog signal Input
VLSI2, (Head A, Right)
Label sensor
12 YEL
Backlog sensor
3 GRN
DC 5V,
Label sensor
8 13
4 RED
Analog voltage output
DLAV1, (Head B, Left)
Label sensor
9 14
5 BLK
Analog signal Input
VLSI1, (Head B, Left)
Label sensor
10 PPL
Head A (Right, X2)
Ribbon sensor
15
