CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
LCD-5
F1 PD LEN
F2 LA LEN
F3 LB LEN
F1: Product diameter measured by the computer.
F2: Head A: Label length measured by the computer.
F3: Head B: Label length measured by the computer.
LCD-6 Print Function (Option)
X
12
F3 PRINT 15
F3: Print Time for optional C60 Hot Stamp Printer (unit 5 m/sec), normally print time is set at 15.
X1: Indicates that printer on left Labeling Head is switched off
X2: Indicates that printer on right Labeling Head is switched off.
X12: Indicates that both left and right printers are switched off.
LCD-7 Push & Press Function (Option)
F1 P & P SD:
F2 P & P PLS:
F3 P & P SPD:
F1: Setting figure for distance between label peel blade and Push & Press attachment.
F2: Pulses per rotation for the Push & Press Attachment motor: 1,200.
F3: Speed of Push & Press Attachment, standard setting: 3,000 (available setting range: 800~4,000)
8 - 5
