VPN Settings
111
DWC-1000 Wireless Controller User’s Guide
Table 6-2. Fields on the IPSEC MODE CONFIG Page
Field Description
Tunnel Mode Select a tunnel mode. Choices are:
• Full Tunnel = every packet destined to the Internet or remote server goes through the tunnel.
• Split Tunnel = traffic destined to the Internet does not pass through the tunnel.
Start IP Address
Enter the first address to be allocated in this pool.
End IP Address
Enter the last address to be allocated in this pool.
Primary DNS
Primary DNS server is used by clients connected to this router to resolve domain names. If
Tunnel Mode = Split Tunnel, the DNS server should be internal domain name server.
Secondary DNS
Secondary DNS Server is used by clients connected to this router to resolve domain names. If
Tunnel Mode = Split Tunnel, the DNS server should be internal domain name server.
Primary WINServer
Enter the primary Windows NetBIOS Name Server used by clients to resolve NetBIOS names.
Secondary WINServer
Enter the secondary Windows NetBIOS Name Server used by clients to resolve NetBIOS names.
Split DNS Names
In a split DNS infrastructure, you create two zones for the same domain, one to be used by the internal network and the other used by
the external network. Split DNS directs internal hosts to an internal domain name server for name resolution and external hosts are
directed to an external domain name server for name resolution.
