Viewing Status and Statistics
142
DWC-1000 Wireless Controller User’s Guide
Field Description
Bytes Transmitted
Number of bytes transmitted to the client station.
Bytes Received Number of bytes received by the client station.
Sessions through the Wireless Controller
Path: STATUS > Active Sessions
The ACTIVE SESSIONS page shows the following information about the active Internet
sessions through the wireless controller:
Local and remote IP addresses
Protocol used during the Internet sessions
State
Figure 7-10. ACTIVE SESSIONS Page
