AP Hardware Capability
Path: STATUS > Global Info > AP H/W Capability
The wireless controller supports access points that have different hardware capabilities,
such as number of radios, supported IEEE 802.11 modes, and software images. Using the
AP HARDWARE CAPABILITY page, you view information about the radio hardware and
IEEE modes supported by access points, as well as software images that are available for
download to the access point.
Table 7-28. Fields on the AP HARDWARE CAPABILITY Page
Field Description
Hardware Type
Shows ID number assigned to each access point hardware type. The wireless controller supports
six different types of access point hardware.
Hardware Type Description
Describes the platform and the supported IEEE 802.11 modes.
Radio Count
Shows whether the hardware supports one radio or two radios.
Image Type
Shows the type of software the hardware requires.
