VPN Settings
114
DWC-1000 Wireless Controller User’s Guide
3. Click Save Settings.
Table 6-4. Fields on the PPTP CLIENT Page
Field Description
PPTP Client Configuration
Enable PPTP Client
Enables or disables the PPTP client. Choices are:
Checked = enable PPTP client.
Unchecked = disable PPTP client.
PPTP Client Configuration
Server IP
Enter the IP address of the PPTP server.
Remote Network
Enter the network address of the remote network that is local to the PPTP server.
Remote Netmask
Enter the subnetmask of the remote network which is local to the PPTP server.
Username
Enter the username that the PPTP Client needs to connect to the PPTP server.
Password
Enter the password that the PPTP Client needs to connect to the PPTP server.
Mppe Encryption
Enables or disables the MPPE encryption client. MPPE is an encryption technology developed by
Microsoft to encrypt point-to-point links over a VPN tunnel. MPPE uses the RC4 algorithm with
either 40- or 128-bit keys. All keys are derived from the cleartext authentication password of the
user. RC4 is stream cipher; therefore, the sizes of the encrypted and decrypted frames are the
same size as the original frame. Choices are:
Checked = enable MPPE encryption.
Unchecked = disable MPPE encryption.
Idle Time Out
If there is no traffic from a user for more than the specified time-out, the connection is
disconnected.
