Page #123 background imageLoading...
Page #123 background image
VPN Settings
123
DWC-1000 Wireless Controller User’s Guide
Certificates
Select the set of certificates OpenVPN server uses:
First Row = set of certificates and keys the server uses.
Second Row = set of newly uploaded certificates and keys.
Enable TLS Authentication Key
Enabling this option adds Transport Layer Security (TLS) authentication, which adds a layer of authentication. TLS uses public key
infrastructure (PKI) to acquire and validate digital certificates. A digital certificate is a cryptographically signed structure that guarantees
the association between at least one identifier and a public key. It is valid for a limited time period and use, subject to certificate policy
conditions. The Certificate Authority issues certificates to client and server. This option can only be checked if a TLS key is uploaded.
Additional VPN Settings
The wireless controller provides more VPN settings than those covered in this chapter. The
following table describes these settings. For more information, go to the page in the web
management interface and then access the wireless controller online help in the Helpful
Hints area (see Figure
3-1 on page 31).
Note: Asterisks in the table below indicate settings that require a DWC-1000-VPN-LIC
License Pack.
VPN Setting Path
L2TP active users SETUP > VPN Settings > L2TP > L2TP Active Users
OpenVPN
Local networking (split tunneling)
Remote networking (site to site)
OpenVPN authentication
SETUP > VPN Settings > OpenVPN > OpenVPN Local Networks (Split
Tunneling)
SETUP > VPN Settings > OpenVPN > OpenVPN Remote Networks (Site To
Site)
SETUP > VPN Settings > OpenVPN > OpenVPN Authentication
PPTP active users SETUP > VPN Settings > PPTP > PPTP Active Users
SSL VPN client
SSL VPN client
Client routes
SETUP > VPN Settings > SSL VPN Client > SSL VPN Client
SETUP > VPN Settings > SSL VPN Client > Configured Client Routes
SSL VPN server
Enable SSL VPN server
Login profiles
Portal layouts
SSL VPN policies
Resources
Port forwarding
SETUP > VPN Settings > SSL VPN Server > SSL VPN Server Enable
SETUP > VPN Settings > SSL VPN Server > Login Profiles
SETUP > VPN Settings > SSL VPN Server > Portal Layouts
SETUP > VPN Settings > SSL VPN Server > SSL VPN Policies
SETUP > VPN Settings > SSL VPN Server > Resources
SETUP > VPN Settings > SSL VPN Server > Port Forwarding
