Viewing Status and Statistics
140
DWC-1000 Wireless Controller User’s Guide
Table 7-7. Fields on the ASSOCIATED CLIENTS STATISTICS Page
Field Description
Packets Received Total number of packets received from the client station.
Bytes Received Total number of bytes received from the client station.
Packets Transmitted Total number of packets transmitted to the client station.
Bytes Transmitted Total number of bytes transmitted to the client station.
Packets Receive Dropped Number of packets received from the client station that were dropped.
Bytes Receive Dropped Number of bytes received from the client station that were dropped.
Packets Transmit Dropped Number of packets transmitted to the client station that were dropped.
Bytes Transmit Dropped Number of bytes transmitted to the client station that were dropped.
Fragments Received Total number of fragmented packets received from the client station.
Fragments Transmitted Total number of fragmented packets transmitted to the client station.
Transmit Retries Number of times transmits to client station succeeded after one or more retries.
Transmit Retries Failed Number of times transmits to client station failed after one or more retries.
TS Violate Packets Received
Count of packets received by an access point from a wireless client for the specified access
category.
TS Violate Packets Transmitted
Count of packets transmitted by an access point to a wireless client for the specified access
category.
Duplicates Received Total number of duplicate packets received from the client station.
Table 7-8. Buttons on the ASSOCIATED CLIENTS STATISTICS Page
Field Description
Refresh Updates the information shown on the page.
View Details
Shows detailed status associated client.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
