D-Link DWC-1000 User Guide

Viewing Status and Statistics
149
DWC-1000 Wireless Controller User’s Guide
Table 7-13. Fields on the ACCESS POINT Page
Field Description
Total Access Points Utilization - Data
Total Access Points Total number of managed access points in the database. This value equals the sum of Managed
Access Points, Connection Failed Access Points, and Discovered Access Points.
Managed Access Points
Number of access points in the Managed AP database that are authenticated, configured, and
have an active connection with the controller.
Discovered Access Points
Access points that have a connection with the controller, but have not been configured
completely. This value includes all managed access points with a Discovered or Authenticated
status.
Connection Failed Access Points
Number of access points that were previously authenticated and managed, but currently don't
have connection with the wireless controller.
Access Points Utilization
Standalone Access Points Number of trusted access points in Standalone mode. Access points in Standalone mode are not
managed by a wireless controller.
Rogue Access Points
Number of rogue access points currently detected on the WLAN. When an access point performs
an RF scan and detects access points that have not been validated, it reports them as rogues.
Authentication Failed Access
Points
Number of access points that failed to establish communication with the controller.
Unknown Access Points
Number of Unknown access points currently detected on the WLAN. If an access point
configured to be managed by the controller is detected through an RF scan at any time that it is
not actively managed it is classified as an Unknown access point.
Rogue access point Mitigation
Limit
Maximum number of access points for which the system can send de-authentication frames.
Rogue access point Mitigation
Count
Number of access points to which the wireless system is currently sending de-authentication
messages to mitigate against rogue access points. A value of 0 indicates that mitigation is not in
progress.
Maximum Managed access points
in Peer Group
Maximum number of access points that can be managed by the cluster.
WLAN Utilization
Total network utilization across all access points managed by this controller. This value is based
on global statistics.
