Viewing Status and Statistics
151
DWC-1000 Wireless Controller User’s Guide
Table 7-14. Fields on the ACCESS POINTS SUMMARY Page
Field Description
MAC Address MAC address of the access point.
IP Address
Network address of the access point.
Age
Amount of time that has passed since the access point was last detected and the information
was last updated.
Status
Access point status. Possible values are:
• Managed = access point profile configuration has been applied to the access point and the
access point is operating in managed mode.
• No Database Entry = access point’s MAC address does not appear in the local or RADIUS
Valid AP database.
• Authentication (Failed AP) = access point failed to be authenticated by the wireless controller
or RADIUS server.
• Failed = wireless controller lost contact with the access point. A failed entry will remain in the
Managed AP database unless you remove it. Note: a managed access point shows a failed
status temporarily during a reset.
• Rogue = access point has not tried to contact the wireless controller and the access point’s
MAC address is not in the Valid AP database.
Radio Wireless radio mode the access point is using.
Channel
Operating channel for the radio.
Table 7-15. Buttons on the ACCESS POINTS SUMMARY Page
Button Description
Delete All Clears all access points, except Managed Access Points, from the page. You do not have to
check the access points before clicking this button. After you click this button, a confirmation
page asks to you to confirm the deletion.
Manage
Configures an access point with a status of Authentication Failed to be managed by the wireless
controller the next time the access point is discovered. Check the box next to the MAC address
of the access point and click Manage. The VALID AP page appears, where you can configure the
access point (see Table 3-2 on page 34). You can then configure the access point and click
Submit to save it in the local Valid AP database. If you use a RADIUS server to validate access
points, add the access point’s MAC address to the access point database on the RADIUS server.
Acknowledge Identifies an access point as an Acknowledged Rogue. Check the box next to the MAC address
of the access point and click Acknowledge. The wireless controller adds the access point to the
Valid Access Point database as an Acknowledged Rogue.
View Details
To view details for a configured access point, check its box next to the MAC address and then
click View Details. The AP RF SCAN STATUS page appears, with detailed information about the
access point (see “AP RF Scan Status” on page 156).
Refresh Updates the information shown on the page.
