Viewing Status and Statistics
160
DWC-1000 Wireless Controller User’s Guide
Field Description
802.11b/g Clients
Total number of IEEE 802.11b/g-only clients that are authenticated.
802.11n Clients
Total number of clients that are IEEE 802.11n-capable and are authenticated. These include
IEEE 802.11a/n, IEEE 802.11b/g/n, 5 GHz IEEE 802.11n, and 2.4GHz IEEE 802.11n.
Maximum Associated Clients
Maximum number of clients that can associate with the wireless system. This is the maximum
number of entries allowed in the Associated Client database.
Detected Clients
Number of wireless clients detected in the wireless network environment.
Maximum Detected Clients
Maximum number of clients that can be detected by the wireless controller. The number is limited
by the size of the Detected Client Database.
Maximum Pre-authentication
History Entries
Maximum number of Client Pre-authentication events that can be recorded by the system.
Total Pre-authentication History
Entries
Current number of Pre-authentication history entries in use by the system.
Maximum Roam History Entries
Maximum number of entries that can be recorded in the roam history for all detected clients.
Total Roam History Entries
Current number of roam history entries in use by the system.
WLAN Statistics
Packets Transmitted
Total packets transmitted across all access points managed by the wireless controller.
Packets Received
Total packets received across all access points managed by the wireless controller.
Packets Transmit Dropped
Total packets transmitted across all access points managed by the wireless controller that were
dropped.
Packets Receive Dropped
Total bytes received across all access points managed by the wireless controller that were
dropped.
Bytes Transmitted
Total bytes transmitted across all access points managed by the wireless controller.
Bytes Received
Total bytes received across all access points managed by the wireless controller.
Bytes Transmit Dropped
Total bytes transmitted across all access points managed by the wireless controller that were
dropped.
Bytes Receive Dropped
Total bytes received across all access points managed by the wireless controller that were
dropped.
Distributed Tunneling
Distributed Tunneling Packets
Transmitted
Total number of packets sent by all access points via distributed tunnels.
Distributed Tunnel Roamed Clients
Total number of clients that successfully roamed away from Home access point using distributed
tunneling.
Distributed Tunnel Clients
Total number of clients that are associated with an access point that are using distributed
tunneling.
Distributed Tunnel Client Details
Total number of clients for which the system was unable to set up a distributed tunnel when client
roamed.
Table 7-22. Buttons on the SUMMARY Page
Button Description
Refresh Updates the information shown on the page.
Clear Statistics
Reset all counters on the page to zero.
