Viewing Status and Statistics
162
DWC-1000 Wireless Controller User’s Guide
Table 7-23. Fields on the PEER CONTROLLER STATUS Page
Field Description
Peer Controller Status
Cluster Controller IP Address
IP address of the wireless controller that controls the cluster.
Peer Controllers
Number of peer controllers in the cluster.
List of Peer Controllers
IP Address
IP address of the peer wireless controller in the cluster.
Vendor ID
Vendor ID of the peer controller software.
Software Version
Software version for the given peer controller.
Protocol Version
Protocol version supported by the software on the peer controller.
Discovery Reason
Discovery method of the given peer controller, which can be through an L2 Poll or IP Poll.
Managed AP Count
Number of access points that the wireless controller manages currently.
Age
Time since last communication with the controller in hours, minutes, and seconds.
