Viewing Status and Statistics
172
DWC-1000 Wireless Controller User’s Guide
Table 7-29. Fields on the CLIENT STATISTICS Page
Field Description
802.11 Clients BAR Graph
The bar graph provides a graphical representation of clients connected through access points managed by the wireless controller.
802.11 Clients - Data
802.11a Clients
Total number of IEEE 802.11a only clients that are authenticated.
802.11b/g Clients
Total number of IEEE 802.11b/g only clients that are authenticated.
802.11n Clients
Total number of clients that are IEEE 802.11n capable and authenticated. These include IEEE
802.11a/n, IEEE 802.11b/g/n, 5 GHz IEEE 802.11n, and 2.4GHz IEEE 802.11n.
Clients - Data
Total Clients
Total number of clients in the database. This total includes clients with an Associated,
Authenticated, or Disassociated status.
Authenticated Clients
Total number of clients in the associated client database with an Authenticated status.
Maximum Associated Clients
Maximum number of clients that can associate with the wireless system. This is the maximum
number of entries allowed in the Associated Client database.
Detected Clients
Number of wireless clients detected in the WLAN.
Maximum Detected Clients
Maximum number of clients that can be detected by the wireless controller. This number is
limited by the size of the Detected Client Database.
Maximum Pre-authentication
History Entries
Maximum number of Client Pre-authentication events that can be recorded by the system.
Total Pre-authentication History
Entries
Current number of Pre-authentication history entries the system is using.
Maximum Roam History Entries
Maximum number of entries that can be recorded in the roam history for all detected clients.
Total Roam History Entries
Number of Pre-authentication history entries the system is using.
