D-Link DWC-1000 User Guide

Basic Configuration
47
DWC-1000 Wireless Controller User’s Guide
Field Description
General Details
Custom Color (#)
Set the background color of the page that appears during the captive portal session.
Header Details
Background
Select whether the login page displayed during the captive portal session will show an image or
color. Choices are:
• Image = show image on the page. Use the Header Background Color field to select a
background color. The maximum size of the image is 100 kb.
• Color = show background color on the page. Use the radio buttons to select an image.
Header Background Color
If you set Background to Color, select a background color for the header.
Custom Color (#)
Use this field to customize the background color.
Header Caption
Enter the text that appears in the header of the login page during the captive portal session.
Caption Font
Select the font for the header text.
Font Size
Select the font size for the header text.
Font Color
Select the font color for the header text.
Login Details
Login Section Title
Enter the text that appears in the title of the login box when the user logs in to the captive portal
session. This field is optional.
Welcome Message
Enter the welcome message that appears when users log in to the captive session successfully.
This field is optional.
Error Message
Enter the error message that appears when users fail to log in to the captive session
successfully. This field is optional.
Footer Details
Change Footer Content
Enables or disables changes to the footer content on the login page. Choices are:
• Checked – enable changes to the footer.
• Unchecked – disable changes to the footer.
Footer Content
If Change Footer Content is checked, enter the text that appears in the footer.
Footer Font Color
If Change Footer Content is checked, select the color of the text that appears in the footer.
d. Under List of Available Profiles, click the profile and the Show Preview button for the
profile you just configured. Confirm that the appearance of the login page suits your
requirements. If not, repeat steps 5c through 5e as necessary.
e. When you are satisfied with the appearance of the custom portal page:
 Under List of Available Profiles, click the profile and then click the Enable
button to enable the profile.
 Under Captive Portal Policies, click a policy and then click the Enable button to
enable the policy.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
