D-Link DWC-1000 User Guide

Advanced Configuration Settings
78
DWC-1000 Wireless Controller User’s Guide
Advanced Configuration Setting Path
LAN DHCP leased clients SETUP > Network Settings > LAN DHCP Leased Clients
LAN DHCP reserved IPs SETUP > Network Settings > LAN DHCP Reserved IPs
MAC-based VLANs SETUP > VLAN Settings > MAC-based VLAN > MAC VLAN
Option mode* SETUP > Internet Settings > Option Mode
Option port setup SETUP > Option Port Settings > Option Setup
ADVANCED > Advanced Network > Option Port Setup*
Option port status SETUP > Option Port Settings > Option Status
ADVANCED > Advanced Network > Option Port Setup*
Option QoS configuration SETUP > QoS > LAN QoS > Policy based LAN QoS
OSPF ADVANCED > Routing > OSPF
ADVANCED > IPv6 > OSPF
Peer controller configuration request status* ADVANCED > Peer Controllers > Configuration Request Status
Peer controller configuration items* ADVANCED > Peer Controllers > Configuration Items
Policy-based QoS SETUP > Option Port Settings > Option Status
Port shaping SETUP > QoS > LAN QoS > Port Shaping Rule
Protocol bindings ADVANCED > Routing > Protocol Bindings
Protocol VLANs SETUP > VLAN Settings > Protocol VLAN
Queue management SETUP > QoS > LAN QoS > Queue Management
Queue scheduler SETUP > QoS > LAN QoS > Queue Scheduler
Remark CoS to DSCP SETUP > QoS > Remark CoS to DSCP.
Router advertisement ADVANCED > IPv6 > IPv6 LAN > Router Advertisement
Routing mode* SETUP > Internet Settings > Routing Mode
SNMP settings TOOLS > Admin > SNMP
SNMP traps ADVANCED > Global > SNMP Trap
Switch settings (including jumbo frames and power savings) ADVANCED > Switch Settings
System check TOOLS > System Check
Universal Plug and Play ADVANCED > Advanced Network > UPnP
Voice VLANs SETUP > VLAN Settings > MAC-based VLAN > Voice VLAN
WLAN global settings SETUP > WLAN Global Settings

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
