Software User Manual D-Link UAP
12/10/09
34CSFP6XXUAP-SWUM100-D13 Viewing Access Point Status Page 27
Section 3: Viewing Access Point Status
This section describes the information you can view from the tabs under the Status heading on the navigation tree of the
UAP Web UI. This section contains the following subsections:
• Viewing Interface Status
• Viewing Events
• Viewing Transmit and Receive Statistics
• Viewing Associated Wireless Client Information
• Viewing Neighboring Access Points
• Viewing Managed AP DHCP Information
VIEWING INTERFACE STATUS
To monitor Ethernet LAN and wireless LAN (WLAN) settings, click the Interfaces tab.
Figure 2: Viewing Interface Status
This page displays the current settings of the UAP. It displays the Wired Settings and the Wireless Settings.
WIRED SETTINGS (INTERNAL INTERFACE)
The Internal interface includes the Ethernet MAC Address, Management VLAN ID, IP Address (IPv4 and IPv6), Subnet
Mask, and DNS information. If you want to change any of these settings, click the Edit link. After you click Edit, you are
redirected to the Ethernet Settings page.
