Software User Manual D-Link UAP
12/10/09
34CSFP6XXUAP-SWUM100-D13 Viewing Transmit and Receive Statistics Page 31
If you enabled the Log Relay Host, clicking Apply will activate remote logging. The AP will send its kernel messages real-
time for display to the remote log server monitor, a specified kernel log file, or other storage, depending on how you
configured the Log Relay Host.
If you disabled the Log Relay Host, clicking Apply will disable remote logging.
VIEWING TRANSMIT AND RECEIVE STATISTICS
The Transmit/Receive page provides some basic information about the current AP and a real-time display of the transmit
and receive statistics for the Ethernet interface on the AP and for the VAPs on both radio interfaces. All transmit and receive
statistics shown are totals since the AP was last started. If you reboot the AP, these figures indicate transmit and receive
totals since the reboot.
To view transmit and receive statistics for the AP, click the Transmit/Receive tab.
Figure 6: Viewing Traffic Statistics
Relay Port Specify the Port number for the syslog process on the Relay Host.
The default port is 514.
Note: To apply your changes, click Apply. Changing some settings might cause the AP to stop and restart system
processes. If this happens, wireless clients will temporarily lose connectivity. We recommend that you change AP
settings when WLAN traffic is low.
Table 8: Log Relay Host
Field Description
