D-Link UAP Software User Manual
12/10/09
Page 88 Configuring VAP QoS Parameters 34CSFP6XXUAP-SWUM100-D13
Figure 30: VAP QoS Parameters
Table 39: VAP QoS Parameters
Field Description
Client QoS Global Admin Mode Enable or disable Client QoS operation on the AP.
Changing this setting will not affect the WMM settings you configure on the QoS page.
Radio Select Radio 1 or Radio 2 to specify which radio to configure.
VAP Specify the VAP that will have the Client QoS settings that you configure.
The QoS settings you configure for the selected VAP will not affect clients that access the
network through other VAPs.
QoS Mode Enable or disable QoS operation on the VAP selected in the VAP menu.
QoS must be enabled globally (from the Client QoS Global Admin Mode field) and on
the VAP (QoS Mode field) for the Client QoS settings to be applied to wireless clients.
Bandwidth Limit Down Enter the maximum allowed transmission rate from the AP to the wireless client in bits
per second. The valid range is 0–4294967295 bps.
A non-zero configured value is rounded down to the nearest 64 Kbps value for use in the
AP, but to no less than 64 Kbps. A value of 0 means that the bandwidth maximum limit is
not enforced in this direction.
Bandwidth Limit Up Enter the maximum allowed client transmission rate to the AP in bits per second. The
valid range is 0–4294967295 bps.
A non-zero configured value is rounded down to the nearest 64 Kbps value for use in the
AP, but to no less than 64 Kbps. A value of 0 means that the bandwidth maximum limit is
not enforced in this direction.
