D-Link UAP Software User Manual
12/10/09
Page 90 Managing Client QoS ACLs 34CSFP6XXUAP-SWUM100-D13
Use the following general steps to configure ACLs:
1. Specify a name for the ACL.
2. Select the type of ACL to add.
3. Add the ACL
4. Add new rules to the ACL.
5. Configure the match criteria for the rules.
6. Apply the ACL to one or more VAPs.
To configure an ACL, click the Client QoS ACL tab.
Figure 31: Client QoS ACL
The following table describes the fields available on the Client QoS ACL page.
Table 40: ACL Configuration
Field Description
ACL Configuration
ACL Name Enter a name to identify the ACL. The name can contain from 1–31 alphanumeric
characters. Spaces are not allowed.
