94D-Link DWR-961 User Manual
Section 3 - Conguration
This screen allows you to create a new queue.
Queue Cong - Add
Name: Enter the name of the queue. This is for user reference only, and
does not aect functionality.
Enable: Check this box to enable the queue.
Interface: Specify the interface this queue will apply to from the dropdown
menu.
Policy: Select whether the queue will employ Strict Priority (SP) or
Weighted Fair Queuing (WFQ).
Precedence: Select the precedence from 1-8. A lower value indicates higher
priority.
Bandwidth
Expression:
If you have selected a WFQ policy, specify if bandwidth will
be expressed as a percentage over overall bandwidth or as an
absolute bit rate.
Shaping Rate
(bit):
If you have selected bits for bandwidth expression, enter a
shaping rate in bits to specify a maximum bandwidth for the
queue. Indicates the shaping rate set on the queue. -1 indicates
no shaping.
Ceiling Rate
(bit):
If you have selected bits for bandwidth expression, specify a
ceiling rate. The ceiling rate is the maximum bandwidth while
bursting.
Percent: If you have selected percent for bandwidth expression, the
percent of total bandwidth assigned to the queue.
