D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
149
both the priority and DSCP are set to be modified.
Replace ToS
Precedence (0-7)
Specify that the IP precedence of the outgoing packet is changed with the new value.
If used without an action priority, the packet is sent to the default TC.
Time Range Name
Tick the check box and enter the name of the Time Range settings that has been
previously configured in the Time Range Settings window. This will set specific times
when this access rule will be implemented on the Switch.
Counter
Here the user can select the counter. By checking the counter, the administrator can
see how many times that the rule was hit.
Ports
When a range of ports is to be configured, the Auto Assign check box MUST be
ticked in the Access ID field of this window. If not, the user will be presented with an
error message and the access rule will not be configured. Ticking the All Ports check
box will denote all ports on the Switch.
VLAN Name
Specify the VLAN name to apply to the access rule.
VLAN ID
Specify the VLAN ID to apply to the access rule.
IPv6 Source Address
Enter the source IPv6 address.
IPv6 Source Address
Mask
Select and enter the source IPv6 address mask.
IPv6 Destination
Address
Enter the destination IPv6 address.
IPv6 Destination
Address Mask
Select and enter the destination IPv6 address mask.
Protocol
Selecting this option instructs the Switch to examine the protocol type value in each
frame's header. Then the user must specify what protocol(s) to include according to
the following guidelines:
Select ICMP to specify that the rule will be applied to ICMP traffic.
Type – Enter the ICMP packet type value.
Code – Enter the ICMP code value.
Select TCP to use the TCP port number contained in an incoming packet as the
forwarding criterion. Selecting TCP requires that you specify a source port mask
and/or a destination port mask.
TCP Source Port - Specify a TCP port number for the source port form (0-65535).
TCP Source Port Mask - Specify a TCP port mask for the source port in hex form
(hex 0x0-0xffff), which you wish to filter.
TCP Destination Port - Specify a TCP port number for the destination port form (0-
65535).
TCP Destination Port Mask - Specify a TCP port mask for the destination port in hex
form (hex 0x0-0xffff) which you wish to filter.
Select UDP to use the UDP port number contained in an incoming packet as the
forwarding criterion. Selecting UDP requires that you specify a source port mask
and/or a destination port mask.
UDP Source Port - Specify a UDP port number for the source port form (0-65535).
UDP Source Port Mask - Specify a UDP port mask for the source port in hex form
(hex 0x0-0xffff), which you wish to filter.
UDP Destination Port - Specify a UDP port number for the destination port form (0-
65535).
UDP Destination Port Mask - Specify a UDP port mask for the destination port in hex
form (hex 0x0-0xffff) which you wish to filter.
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
