xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
131
create dot1v_protocol_group group_id
Purpose
Used to create a protocol group for protocol VLAN function.
Syntax create dot1v_protocol_group group_id <id> {group_name <name 32>}
Description
This command creates a protocol group for protocol VLAN function.
Parameters
group_id
− The ID of a protocol group which is used to identify a set of protocols.
group_name − The name of the protocol group. The maximum length is 32 characters.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To create a protocol group:
DES-3528:admin# create dot1v_protocol_group group_id 1 group_name General_Group
Command: create dot1v_protocol_group group_id 1 group_name General_Group
Success.
DES-3528:admin#
config dot1v_protocol_group
Purpose
Used to add/delete a protocol to/from a protocol group.
Syntax config dot1v_protocol_group [group_id <id> | group_name <name 32>] [add protocol
[ethernet_2 | ieee802.3_snap | ieee802.3_llc] <protocol_value> | delete protocol
[ethernet_2 | ieee802.3_snap | ieee802.3_llc] <protocol_value>]
Description
This command adds/deletes a protocol to/from a protocol group.The selection of a protocol
can be a pre-defined protocol type or a user specified protocol type.
Parameters
group_id
− The ID of protocol group which is used to identify a set of protocols.
group_name − The name of the protocol group. The maximum length is 32 chars.
protocol_value − The protoocl vlaue is used to identify a protocol of the frame type specified
Depending on the frame type, the octet string will have one of the following values: The form
of the input is 0x0 to 0xffff.
For 'ethernet'II, this is a 16-bit (2-octet) hex value.
Example: Ipv4 is 800, ipv6 is 86dd, ARP is 806,.. and so on.
For ' IEEE802.3 SNAP ',this is this is a 16-bit (2-octet) hex value.
Access Point (DSAP) and second octet for Source.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To add a protocol IPv6 to protocol group 1:
DES-3528:admin# config dot1v_protocol_group group_id 1 add protocol Ethernet_2 86DD
Command: config dot1v_protocol_group group_id 1 add protocol Ethernet_2 86DD
Success.
DES-3528:admin#
