Connectivity Fault Management Commands
The Connectivity Fault Management commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameters
create cfm md <string 22> level <int 0-7>
config cfm md <string 22> {mip [none | auto | explicit] | sender_id [none | chassis | manage |
chassis_manage]} (1)
create cfm ma <string 22> md <string 22>
config cfm ma <string 22> md <string 22> {vlanid <vlanid 1-4094> | mip [none | auto | explicit | defer] |
sender_id [none | chassis | manage | chassis_manage | defer] | ccm_interval [10ms |
100ms | 1sec | 10sec | 1min | 10min] | mepid_list [add | delete] <mepid_list>}(1)
create cfm mep <string 32> mepid <int 1-8191> md <string 22> ma <string 22> direction [inward |
outward] port <port>
config cfm mep [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {state
[enable | disable] | ccm [enable | disable] | pdu_priority <int 0-7> | fault_alarm [all |
mac_status | remote_ccm | error_ccm | xcon_ccm | none] | alarm_time <centiseconds
250 -1000> | alarm_reset_time <centiseconds 250-1000>}(1)
delete cfm mep [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>]
delete cfm ma <string 22> md <string 22>
delete cfm md <string 22>
enable cfm
disable cfm
config cfm ports <portlist> state [enable | disable]
show cfm ports <portlist>
show cfm {[md <string 22> {ma <string 22> {mepid <int 1-8191>}} | mepname <string 32>]}
show cfm remote_mep [mepname <string 32> | md <string 22> ma <string 22> mepid <int 1-8191>]
remote_mepid <int 1-8191>
show cfm fault {md <string 22> {ma <string 22>}}
show cfm port <port> {level <int 0-7> | direction [inward | outward] | vlanid <vlanid 1-4094>}
show cfm mipccm
show cfm pkt_cnt {[ports <portlist> {[rx | tx]} | [rx | tx] | ccm]}
clear cfm pkt_cnt {[ports <portlist> {[rx | tx]} | [rx | tx] | ccm]}
cfm loopback <macaddr> [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>]
{num <int 1-65535> | [length <int 0-1500> | pattern <string 1500>] | pdu_priority <int 0-
7>}
cfm linktrace <macaddr> [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>]
{ttl <int 2-255> | pdu_priority <int 0-7>}
show cfm linktrace [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {trans_id
<uint>}
delete cfm linktrace {[md <string 22> {ma <string 22> {mepid <int 1-8191>}} | mepname <string 32>]}
config cfm ccm_fwd [software | hardware]
show cfm ccm_fwd
