xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide
98
Forwarding Database Commands
The layer 2 forwarding database commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameters
create fdb <vlan_name 32> <macaddr> [port <port> | drop]
create fdb vlanid <vidlist> <macaddr> [port <port> | drop]
create multicast_fdb <vlan_name 32> <macaddr>
config multicast_fdb <vlan_name 32> <macaddr> [add | delete] <portlist>
config fdb aging_time <sec 10-1000000>
delete fdb <vlan_name 32> <macaddr>
clear fdb [vlan <vlan_name 32> | port <port> | all]
show multicast_fdb {[vlan <vlan_name 32> | vlanid <vidlist>] | mac_address <macaddr>}
show fdb {[port <port> | vlan <vlan_name 32> |vlanid <vidlist> | mac_address <macaddr> | static |
aging_time | security]}
config multicast
vlan_filtering_mode
[vlanid <vidlist> | vlan <vlan_name 32> | all ] [forward_all_groups |
forward_unregistered_groups | filter_unregistered_groups]
show multicast
vlan_filtering_mode
{[vlanid <vidlist> | vlan <vlan_name 32>]}
Each command is listed, in detail, in the following sections.
create fdb
Purpose
Used to create a static entry to the unicast MAC address forwarding table (database).
Syntax create fdb <vlan_name 32> <macaddr> [port <port> | drop]
Description
This command will make an entry into the Switch’s unicast MAC address forwarding
database.
Parameters
<vlan_name 32> − The name of the VLAN on which the MAC address resides.
<macaddr> − The MAC address that will be added to the forwarding table.
port <port> − The port number corresponding to the MAC destination address. The Switch
will always forward traffic to the specified device through this port.
drop - Specifies that all the ports specified will drop the packet of the previously configured
MAC
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command
Example usage:
To create a unicast MAC FDB entry:
DES-3528:admin# create fdb default 00-00-00-00-01-02 port 5
Command: create fdb default 00-00-00-00-01-02 port 5
Success.
DES-3528:admin#
