config voice_vlan oui
Purpose
Used to configure the user defined OUI (Organizationally Unique Identifier) of Voice device
for voice VLAN.
Syntax config voice_vlan oui [add | delete] <macaddr> < macmask> {description <desc 32>}
Description
This command is used to configure the user-defined OUI for voice traffic. The OUI is used to
identify the voice traffic. There are a number of pre-defined OUIs. The user can further define
the user-defined OUIs. However, the user defined OUI cannot be the same as pre-defined
OUI.
Parameters add – Adds a user defined OUI for a voice device vendor.
delete - Deletes a user defined OUI for a voice device vendor.
<macaddr> - Specifies the user difined OUI MAC address.
<macmask> - Specifies the user difined OUI MAC address mask.
description - Specifies the descriptions for the user defined OUI.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To add a user defined OUI of Voice device:
DES-3528:admin# config voice_vlan oui add 00-0A-0B-00-00-00 FF-FF-FF-00-00-00
Command: config voice_vlan oui add 00-0A-0B-00-00-00 FF-FF-FF-00-00-00
Success.
DES-3528:admin#
config voice_vlan ports
Purpose
Used to enable or disable the voice VLAN function on ports.
Syntax config voice_vlan ports [<portlist> | all] [state [enable | disable] | mode [auto | manual]]
Description
This command is used to enable/disable the voice VLAN function on ports.
Parameters <portlist> – Specifies a range of ports to configure.
all - Specifies to configure all ports.
state – Specifies the voice VLAN function state on ports.
• enable – Enables the voice VLAN function state on ports.
• disable - Disables the voice VLAN function state on ports.
mode – Specifies the mode used by the voice VLAN ports.
auto – Specifies that the voice VLAN ports’ mode will be set to automatic.
manual - Specifies that the voice VLAN ports’ mode will be set to manual.
Restrictions
Only Administrator and Operator and Power-User-level users can issue this command.
Example usage:
To configure the voice VLAN portlist 4-6 enable:
DES-3528:admin# config voice_vlan ports 4-6 state enable
Command: config voice_vlan ports 4-6 state enable
Success.
DES-3528:admin#
