Danfoss Vacon NXP Series User Manual

Drive type W1 W2 H1 H2 H3 D1 Ø E1Ø
E2Ø
(1)
E3Ø
E4Ø
(2)
0048 2-0061 2
0038 5-0061 5
0004 6-0034 6
195
(7.68)
148
(5.83)
558
(21.97)
541
(21.3)
519
(20.43)
237
(9.33)
9
(0.35)
3 x 37
(3 x 1.46)
-
(-)
3 x 37
(3 x 1.46)
3 x 28.3
(3 x 1.11)
1
FR5 only
2
FR5 and FR6 only
12.2.2.2 Dimensions for FR7
B
C
A
e30bf999.10
Illustration 45: Dimensions of the VACON
®
NXS/NXP AC Drive, FR7
Table
21: Dimensions in mm (in inch) of the VACON
®
NXS/NXP AC Drive, FR7
Drive type W1 W2 H1 H2 H3 D1 Ø E1Ø E2Ø E3Ø
0075 2-0114 2
0072 5-0105 5
0041 6-0052 6
237
(9.33)
190
(7.48)
630
(24.80)
614
(24.17)
591
(23.27)
257
(10.12)
9
(0.35)
3 x 50.3
(3 x 1.98)
3 x 50.3
(3 x 1.98)
3 x 28.3
(3 x 1.11)
Specifications
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G | 127
Danfoss A/S © 2018.06
