12.2.3.3
Dimensions for Flange Mounting, FR9
W1
W2
Ø
W3
M5
H1
W4
W4
W5
H5
H3
H3
H3
H5
H7
H2
H4
H4
D1
D2
D3
H6
A
B
e30bg008.10
A
Top
B
Opening
Illustration
53:
Dimensions of the VACON
®
NXS/NXP AC Drive, FR9
Table
31: Dimensions in mm (in inch) of the VACON
®
NXS/NXP AC Drive, FR9, part 1
Drive type
W1
W2
W3
W4
W5
D1
D2
D3
Ø
0261 2-0300 2
0261 5-0300 5
0125 6-0208 6
530
(20.87)
510
(20.08)
485
(19.09)
200
(7.87)
5.5
(0.22)
362
(14.25)
340
(13.39)
109
(4.29)
21
(0.83)
Specifications
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G
| 135
Danfoss A/S ©
2018.06
134
