Danfoss VLT AQUA Drive FC 202 Design Manual

VLT
®
AQUA Drive FC 202
N560 N630
High/normal load HO NO HO NO
(High overload=150% current during 60 s, normal
overload=110% current during 60 s)
Typical shaft output at 525 V [kW] 400 450 450 500
Typical shaft output at 575 V [hp] 500 600 600 650
Typical shaft output at 690 V [kW] 500 560 560 630
Enclosure size E1h/E3h E1h/E3h
Output current (3-phase)
Continuous (at 525 V) [A] 523 596 596 630
Intermittent (60 s overload) (at 525 V) [A] 785 656 894 693
Continuous (at 575/690 V) [A] 500 570 570 630
Intermittent (60 s overload) (at 575/690 V) [A] 750 627 855 693
Continuous kVA (at 525 V) [kVA] 498 568 568 600
Continuous kVA (at 575 V) [kVA] 498 568 568 627
Continuous kVA (at 690 V) [kVA] 598 681 681 753
Maximum input current
Continuous (at 525 V) [A] 504 574 574 607
Continuous (at 575/690 V) [A] 482 549 549 607
Maximum number and size of cables per phase (E1h)
- Mains and motor without brake [mm
2
(AWG)]
5x240 (5x500 mcm) 5x240 (5x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
4x240 (4x500 mcm) 4x240 (4x500 mcm)
- Brake or regeneration [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm)
Maximum number and size of cables per phase (E3h)
- Mains and motor without brake [mm
2
(AWG)]
6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm)
- Load share or regeneration [mm
2
(AWG)]
4x185 (4x350 mcm) 4x185 (4x350 mcm)
Maximum external mains fuses [A]
1)
800 800
Estimated power loss at 600 V [W]
2), 3)
6833 8076 8069 9208
Estimated power loss at 690 V [W]
2), 3)
6678 7852 7848 8921
Eciency
3)
0.98 0.98
Output frequency [Hz] 0–500 0–500
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176)
Power card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Table 7.10 Electrical Data for Enclosures E1h/E3h, Mains Supply 3x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
