Danfoss VLT AutomationDrive FC 302 Programming Guide

Table 194: Preset Referenece Bits
Preset ref. bit
2
1
0
Preset ref. 0
0
0
0
Preset ref. 1
0
0
1
Preset ref. 2
0
1
0
Preset ref. 3
0
1
1
Preset ref. 4
1
0
0
Preset ref. 5
1
0
1
Preset ref. 6
1
1
0
Preset ref. 7
1
1
1
Parameter 3-11 Jog Speed [Hz]
Table 195: Parameter 3-11 Jog Speed [Hz]
3-11 Jog Speed [Hz]
Default value: Size related
Parameter type: Range, 0 - par. 4-14 Hz
Setup: All setups
Conversion index: -1
Data type: Uint16
Change during operation: True
The jog speed is a fixed output speed at which the drive is running when the jog function is activated. See also parameter 3-80 Jog/
Homing Ramp Time.
Parameter 3-12 Catch Up/Slow Down Value
Table 196: Parameter 3-12 Catch Up/Slow Down Value
3-12 Catch Up/Slow Down Value
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: -2
Data type: Int16
Change during operation: True
Enter a percentage (relative) value to be either added to or deducted from the actual reference for catch up or slow down. If catch
up is selected via 1 of the digital inputs (parameter 5-10 Terminal 18 Digital Input to parameter 5-15 Terminal 33 Digital Input), the
percentage (relative) value is added to the total reference. If slow down is selected via 1 of the digital inputs (parameter 5-10 Termi-
nal 18 Digital Input to parameter 5-15 Terminal 33 Digital Input), the percentage (relative) value is deducted from the total reference.
Obtain extended functionality with the DigiPot function. See parameter group 3-9* Digital Potentiometer.
Parameter 3-13 Reference Site
Table 197: Parameter 3-13 Reference Site
3-13 Reference Site
Default value: [0] Linked to hand/auto
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select which reference site to activate.
AU275636650261en-000101 / 130R0334 | 129Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
