Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[0]*
No function
[2]
Analog in 53
[4]
Analog in 53 inv
[6]
Analog in 54
[8]
Analog in 54 inv
[10]
Analog in X30-11
[12]
Analog in X30-11 inv
[14]
Analog in X30-12
[16]
Analog in X30-12 inv
Parameter 4-21 Speed Limit Factor Source
Table 272: Parameter 4-21 Speed Limit Factor Source
4-21 Speed Limit Factor Source
Default value: [0] No function
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select an analog input for scaling the settings in parameter 4-19 Max Output Frequency 0–100% (or the other way around). The signal
levels corresponding to 0% and 100% are defined in the analog input scaling, for example parameter group 6-1* Analog Input 1. This
parameter is only active when parameter 1-00 Configuration Mode is in [4] Torque Open Loop.
Option
Name
Description
[0]*
No function
[2]
Analog in 53
[4]
Analog in 53 inv
[6]
Analog in 54
[8]
Analog in 54 inv
[10]
Analog in X30-11
[12]
Analog in X30-11 inv
[14]
Analog in X30-12
[16]
Analog in X30-12 inv
Parameter 4-23 Brake Check Limit Factor Source
Table 273: Parameter 4-23 Brake Check Limit Factor Source
4-23 Brake Check Limit Factor Source
Default value: [0] DC-link Voltage
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334 | 157Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
