Danfoss VLT AutomationDrive FC 302

Digital input function
Select
Terminal
DigiPot decrease
[56]
All
DigiPot clear
[57]
All
DigiPot hoist
[58]
All
Counter A (up)
[60]
Terminal 29, 33
Counter A (down)
[61]
Terminal 29, 33
Reset Counter A
[62]
All
Counter B (up)
[63]
Terminal 29, 33
Counter B (down)
[64]
Terminal 29, 33
Reset Counter B
[65]
All
Mech. brake feedb.
[70]
All
Mech. brake feedb. inv.
[71]
All
PID error inv.
[72]
All
PID reset I-part
[73]
All
PID enable
[74]
All
MCO specific
[75]
All
Reset maint. word
[78]
PTC card 1
[80]
All
PROFIdrive OFF2
[91]
All
PROFIdrive OFF3
[92]
All
Light-load detection
[94]
All
Evacuation
[95]
All
Mains loss
[96]
Terminal 32, 33
Mains loss inverse
[97]
Terminal 32, 33
Start edge triggered
[98]
All
Safety option reset
[100]
–
Active CAM table
[104]
Set vir. mas. pos. to actual
[105]
Enable master offset
[108]
All
Start virtual master
[109]
All
Start homing
[110]
All
Activate touch
[111]
All
Relative position
[112]
All
AU275636650261en-000101 / 130R0334178 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
