Danfoss VLT AutomationDrive FC 302

Parameter 5-16 Terminal X30/2 Digital Input
Table 341: Parameter 5-16 Terminal X30/2 Digital Input
5-16 Terminal X30/2 Digital Input
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-17 Terminal X30/3 Digital Input
Table 342: Parameter 5-17 Terminal X30/3 Digital Input
5-17 Terminal X30/3 Digital Input
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-18 Terminal X30/4 Digital Input
Table 343: Parameter 5-18 Terminal X30/4 Digital Input
5-18 Terminal X30/4 Digital Input
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-19 Terminal 37 Safe Stop
Table 344: Parameter 5-19 Terminal 37 Safe Stop
5-19 Terminal 37 Safe Stop
Default value: Size related
Parameter type: Option
Setup: 1 setup
Conversion index: –
Data type: Uint8
Change during operation: True
N O T I C E
Options [4] PTC 1 Alarm to [9] PTC 1 & Relay W/A are only available when the VLT® PTC Thermistor Card MCB 112 is connected.
N O T I C E
Selecting Auto Reset/Warning enables automatic restart of the drive.
Use this parameter to configure the Safe Torque Off functionality. A warning message makes the drive coast the motor and enables
the automatic restart. An alarm message makes the drive coast the motor and requires a manual restart (via a fieldbus, Digital I/O, or
by pressing [RESET] on the LCP). When the VLT® PTC Thermistor Card MCB 112 is mounted, configure the PTC options to get the full
benefit from the alarm handling.
Op-
tion
Name
Description
[1]
Safe stop alarm
Coasts the drive when Safe Torque Off is activated. Manual reset from LCP, digital input, or fieldbus.
[3]
Safe stop warn-
ing
Coasts the drive when Safe Torque Off is activated (terminal 37 off). When the Safe Torque Off cir-
cuit is re-established, the drive continues without manual reset.
[4]
PTC 1 alarm
Coasts the drive when Safe Torque Off is activated. Manual reset from LCP, digital input, or fieldbus.
