Danfoss VLT AutomationDrive FC 302

Option
Function
[63]
Comparator 3
See parameter group 13-1* Comparators. If comparator 3 is evaluated as true, the output goes high.
Otherwise, it is low.
[64]
Comparator 4
See parameter group 13-1* Comparators. If comparator 4 is evaluated as true, the output goes high.
Otherwise, it is low.
[65]
Comparator 5
See parameter group 13-1* Comparators. If comparator 5 is evaluated as true, the output goes high.
Otherwise, it is low.
[66]
Comparator 6
See parameter group 13-1* Comparators. If comparator 6 is evaluated as true, the output goes high.
Otherwise, it is low.
[67]
Comparator 7
See parameter group 13-1* Comparators. If comparator 7 is evaluated as true, the output goes high.
Otherwise, it is low.
[68]
Comparator 8
See parameter group 13-1* Comparators. If comparator 8 is evaluated as true, the output goes high.
Otherwise, it is low.
[69]
Comparator 9
See parameter group 13-1* Comparators. If comparator 9 is evaluated as true, the output goes high.
Otherwise, it is low.
[70]
Logic rule 0
See parameter group 13-4* Logic Rules. If logic rule 0 is evaluated as true, the output goes high.
Otherwise, it is low.
[71]
Logic rule 1
See parameter group 13-4* Logic Rules. If logic rule 1 is evaluated as true, the output goes high.
Otherwise, it is low.
[72]
Logic rule 2
See parameter group 13-4* Logic Rules. If logic rule 2 is evaluated as true, the output goes high.
Otherwise, it is low.
[73]
Logic rule 3
See parameter group 13-4* Logic Rules. If logic rule 3 is evaluated as true, the output goes high.
Otherwise, it is low.
[74]
Logic rule 4
See parameter group 13-4* Logic Rules. If logic rule 4 is evaluated as true, the output goes high.
Otherwise, it is low.
[75]
Logic rule 5
See parameter group 13-4* Logic Rules. If logic rule 5 is evaluated as true, the output goes high.
Otherwise, it is low.
[80]
SL digital output A
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[38] Set dig. out. A high is executed. The output goes low whenever the smart logic action [32] Set
dig. out. A low is executed.
[81]
SL digital output B
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[39] Set dig. out. B high is executed. The output goes low whenever the smart logic action [33] Set
dig. out. B low is executed.
[82]
SL digital output C
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[40] Set dig. out. C high is executed. The output goes low whenever the smart logic action [34] Set
dig. out. C low is executed.
[83]
SL digital output D
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[41] Set dig. out. D high is executed. The output goes low whenever the smart logic action [35] Set
dig. out. D low is executed.
[84]
SL digital output E
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[42] Set dig. out. E high is executed. The output goes low whenever the smart logic action [36] Set
dig. out. E low is executed.
[85]
SL digital output F
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[43] Set dig. out. F high is executed. The output goes low whenever the smart logic action [37] Set
dig. out. F low is executed.
AU275636650261en-000101 / 130R0334 | 201Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
