Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Function
[246]
Emcy mode was act.
The drive has been operating in emergency mode.
[247]
Emergency mode
The drive is operating in emergency mode. See parameter group 24-0* Emergency Mode.
[249]
Emcy m. OPR unex-
pected
Emergency mode input or safe stop is not operating as expected, for example, live zero monitor-
ing on an analog input is activated.
[250]
Emcy mode limits
During emergency mode operation, 1 of the critical alarms has been activated and suppressed by
emergency mode. This may lead to reduced drive performance and expected operation lifetime
before service is required.
[254]
Testing emcy mode
Emergency mode is activated in a special test mode where the drive stops on all alarms.
Parameter 5-30 Terminal 27 Digital Output
Table 356: Parameter 5-30 Terminal 27 Digital Output
5-30 Terminal 27 Digital Output
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the function from the available digital output range and the additional options [60] Counter A (up), [61] Counter A (down), [63]
Counter B (up), and [64] Counter B (down). Counters are used in smart logic control functions. All functions are described in Table 353
and Table 355.
Option
Name
Description
[0]
No operation
[1]
Control ready
[2]
Drive ready
[3]
Coast and reset inv
[4]
Enable/no warning
[5]
Running
[6]
Running/no warning
[7]
Run in range/no warn
[8]
Run on ref/no warn
[9]
Alarm
[10]
Alarm or warning
[11]
At torque limit
[12]
Out of current range
[13]
Below current, low
[14]
Above current, high
[15]
Out of speed range
[16]
Below speed, low
[17]
Above speed, high
AU275636650261en-000101 / 130R0334 | 205Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
