Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[4]
Position error
N O T I C E
This option is only available with software version 48.XX.
The position is outside its limits set in parameter 3-06 Minimum Position and parameter
3-07 Maximum Position.
[5]
Position limit
N O T I C E
This option is only available with software version 48.XX.
The position error exceeds the value in parameter 4-71 Maximum Position for the time
set in parameter 4-72 Position Error Timeout.
[6]
Touch on target
N O T I C E
This option is only available with software version 48.XX.
Target position is reached in touch probe position mode.
[7]
Touch activated
N O T I C E
This option is only available with software version 48.XX.
Touch probe positioning is active. The drive monitors the touch probe sensor input.
[8]
Touch sensor found
N O T I C E
This option is only available with software version 48.XX.
The touch sensor has been detected.
[9]
Vir. master on ref
N O T I C E
This option is only available with software version 48.XX.
The virtual master is running on the set reference.
[10]
T18DI status
[11]
T19DI status
[12]
T27DI status
[13]
T29DI status
[14]
T32DI status
[15]
T33DI status
[16]
T37DI status
The input goes high whenever T37 has 0 V and goes low whenever T37 has 24 V.
[17]
X30/2 DI status
[18]
X30/3 DI status
AU275636650261en-000101 / 130R0334276 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
