Danfoss VLT AutomationDrive FC 302 Programming Guide

Parameter 8-56 Preset Reference Select
Table 533: Parameter 8-56 Preset Reference Select
8-56 Preset Reference Select
Default value: [3] Logic OR
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the trigger for the preset reference selection.
Option
Name
Description
[0]
Digital input
A digital input triggers the preset reference selection.
[1]
Bus
A serial communication port or the fieldbus triggers the preset reference selection.
[2]
Logic AND
The fieldbus/serial communication port and a digital input trigger the preset reference selection.
[3]*
Logic OR
The fieldbus/serial communication port or a digital input triggers the preset reference selection.
Parameter 8-57 PROFIdrive OFF2 Select
Table 534: Parameter 8-57 PROFIdrive OFF2 Select
8-57 PROFIdrive OFF2 Select
Default value: [3] Logic OR
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select control of the drive OFF2 selection via the terminals (digital input) and/or via the fieldbus. This parameter is active only when
parameter 8-01 Control Site is set to [0] Digital and ctrl. word and parameter 8-10 Control Word Profile is set to [1] PROFIdrive profile.
Option
Name
Description
[0]
Digital input
[1]
Bus
[2]
Logic AND
[3]*
Logic OR
Parameter 8-58 PROFIdrive OFF3 Select
Table 535: Parameter 8-58 PROFIdrive OFF3 Select
8-58 PROFIdrive OFF3 Select
Default value: [3] Logic OR
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select control of the drive OFF3 selection via the terminals (digital input) and/or via the fieldbus. This parameter is active only when
parameter 8-01 Control Site is set to [0] Digital and ctrl. word and parameter 8-10 Control Word Profile is set to [1] PROFIdrive profile.
AU275636650261en-000101 / 130R0334 | 301Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
